Specifications

Printing Method

9-pin, impact dot matrix, wide carriage

Print Speed (cps @10 cpi)

High Speed Draft

560

Draft

420

(NLQ (9-pin) / LQ (24-pin

84

Maximum Form Parts

6

Input Buffer

20 KB

MTBF

8,000 POH @ 25% duty

Print Head Life

300 million characters

Sound Level

(55 dB(A

Standard Interface

Parallel, Serial

Printer Language

ESC/P, IBM ProPrinter II emulation

Physical Dimensions

(Height (inches

14.5"

(Width (inches

27.6"

(Depth (inches

15"

(Weight (lbs

63.9 lbs
